Standard Protocol Tags

Tags and queries are the usual way for independently written QuantumSavory processes to interact. A protocol publishes a classical fact as a tag or as a message, and another protocol queries for that fact when it needs a resource, an update, or a control-plane event.

Users are free and encouraged to define their own tags. A small symbolic tag is often the clearest choice for local control flow:

tag!(reg[1], :ready_for_my_protocol, 7)
query(reg, :ready_for_my_protocol, W)

The standard tags below are different: they are the shared vocabulary used by ProtocolZoo. Use them when a custom protocol should cooperate with existing zoo protocols such as EntanglerProt, SwapperProt, EntanglementTracker, CutoffProt, EntanglementConsumer, switch protocols, QTCP controllers, or MBQC purification protocols.

Custom Tags Versus Standard Tags

Use custom tags when the meaning is private to your protocol. Use standard tags when another protocol is expected to understand the metadata. This convention is what lets a custom component fit into an existing stack without directly calling the internals of another protocol.

For example, EntanglerProt marks generated links with EntanglementCounterpart. SwapperProt can then find such links by querying for that tag, and EntanglementTracker can keep the metadata coherent after a swap. A custom entangler can participate in the same stack by producing the same tag schema.

Typed tags are represented as Tag(TypeName, fields...). They can be attached to register slots with tag!, sent as messages with put!, and matched with query, queryall, or querydelete!.

Entanglement Metadata Interface

These tags are the main interface between the first-generation repeater protocols in ProtocolZoo.

EntanglementCounterpart

Tag(EntanglementCounterpart, remote_node, remote_slot, pair_id)

Storage location: register slots.

Meaning: the local slot is entangled with remote_node.remote_slot, and the pair is identified by pair_id.

Protocol interface:

• EntanglerProt produces reciprocal EntanglementCounterpart tags when it creates a Bell pair.
• SwapperProt consumes two such tags at the swapping node and sends update messages to the former endpoints.
• EntanglementTracker rewrites counterpart metadata after swap updates.
• CutoffProt queries it before deleting stale pairs and sending deletion notices.
• EntanglementConsumer queries reciprocal counterparts when it consumes an end-to-end pair.
• SimpleSwitchDiscreteProt queries it to find switch-client links that can be matched or deleted.

Typical query:

query(reg, EntanglementCounterpart, remote_node, W, W; assigned=true)
query(slot, EntanglementCounterpart, remote_node, remote_slot, pair_id)

If you create these tags manually, prefer a fresh id for a newly generated pair:

pair_id = fresh_entanglement_id()
tag!(net[1][1], EntanglementCounterpart, 2, 1, pair_id)
tag!(net[2][1], EntanglementCounterpart, 1, 1, pair_id)

EntanglementHistory

Tag(EntanglementHistory,
    remote_node, remote_slot,
    swap_remote_node, swap_remote_slot,
    swapped_local,
    local_chunk_id, swapped_chunk_id)

Storage location: register slots at nodes that performed swaps.

Meaning: the slot used to be entangled with remote_node.remote_slot, but was locally swapped with swapped_local, whose remote endpoint was swap_remote_node.swap_remote_slot.

Protocol interface:

• SwapperProt creates history tags after a swap.
• EntanglementTracker consumes or updates history tags when delayed update or delete messages arrive for a pair whose local metadata has already changed.

Typical query:

query(slot, EntanglementHistory, old_node, old_slot, W, W, W, W, W)

EntanglementUpdateX And EntanglementUpdateZ

Tag(EntanglementUpdateX,
    target_pair_id, other_pair_id,
    past_local_node, past_local_slot, past_remote_slot,
    new_remote_node, new_remote_slot,
    correction)

Tag(EntanglementUpdateZ,
    target_pair_id, other_pair_id,
    past_local_node, past_local_slot, past_remote_slot,
    new_remote_node, new_remote_slot,
    correction)

Storage location: message buffers.

Meaning: a remote node performed a swap. The receiver should update the counterpart metadata for the target pair, combine in the other pair-id chunk, and apply the indicated Pauli-frame correction if needed.

Protocol interface:

• SwapperProt sends these messages to the former endpoints of the two swapped links.
• EntanglementTracker consumes them and updates local counterpart/history metadata.
• Custom protocols that perform their own swaps can use these tags to notify the standard tracker.

Typical query:

querydelete!(messagebuffer(net, node),
    EntanglementUpdateX, W, W, W, W, W, W, W, W)

EntanglementDelete

Tag(EntanglementDelete, target_pair_id, send_node, send_slot, rec_node, rec_slot)

Storage location: message buffers and, temporarily, register slots.

Meaning: one side of a pair has been deleted or decohered, and the other side must clear matching metadata and trace out the corresponding qubit.

Protocol interface:

• CutoffProt sends deletion messages after it removes stale entanglement.
• EntanglementTracker consumes deletion messages and forwards or stores them when swaps have changed the endpoint metadata.
• SwapperProt and cleanup logic rely on this tag to avoid leaving stale counterpart information behind.

Typical query:

querydelete!(messagebuffer(net, node),
    EntanglementDelete, target_pair_id, W, W, node, W)

Entanglement IDs

Some standard entanglement tags carry fields of type EntanglementID. These ids are not just display metadata. They are the identity of an entangled pair across swap, update, and delete events.

If a custom protocol manipulates EntanglementCounterpart, EntanglementHistory, EntanglementUpdateX, EntanglementUpdateZ, or EntanglementDelete, it must preserve the id semantics expected by EntanglerProt, SwapperProt, EntanglementTracker, CutoffProt, and EntanglementConsumer.

Use:

• fresh_entanglement_id() for a newly generated physical pair.
• combine_entanglement_ids(id1, id2) when a swap combines pair-id chunks.
• NO_ENTANGLEMENT_ID only for legacy/custom workflows that do not participate in pair-id-sensitive tracking.

Switch Interface

SwitchRequest

Tag(SwitchRequest, requester, remote_node)

Storage location: switch node message buffers.

Meaning: requester asks the switch to establish entanglement with remote_node.

Protocol interface:

• Clients send this message to a switch node.
• SimpleSwitchDiscreteProt consumes these requests, updates its backlog, and attempts switch-mediated entanglement according to its assignment algorithm.

Typical query:

querydelete!(messagebuffer(net, switch_node), SwitchRequest, W, W)

QTCP Interface

QTCP tags are subsystem-specific control-plane messages. They are standard within the QTCP controller stack and are useful when customizing QTCP behavior.

The figure summarizes the QTCP controller API: applications submit Flow requests to end-node controllers, end nodes create and acknowledge QDatagram messages, network-node controllers request hop-by-hop link resources, and link controllers answer with the link-level reply tags consumed by the higher layers.

Flow Requests And Endpoints

Tag(Flow, src, dst, npairs, uuid)
Tag(QTCPPairBegin, flow_uuid, flow_src, flow_dst, seq_num, memory_slot, start_time)
Tag(QTCPPairEnd, flow_uuid, flow_src, flow_dst, seq_num, memory_slot, start_time)

Storage location: message buffers for Flow, node registers for pair-completed notifications.

Protocol interface:

• Users or applications put Flow at the source node to request end-to-end Bell pairs.
• EndNodeController consumes Flow, creates QDatagram messages, and emits QTCPPairBegin or QTCPPairEnd when a pair reaches the endpoints.
• Custom end-node controllers can use the same tags to remain compatible with the rest of the QTCP stack.

Typical queries:

querydelete!(messagebuffer(net, src), Flow, src, W, W, W)
query(net[src], QTCPPairBegin, flow_uuid, src, dst, W, W, W)
query(net[dst], QTCPPairEnd, flow_uuid, src, dst, W, W, W)

Datagram And Acknowledgement Messages

Tag(QDatagram, flow_uuid, flow_src, flow_dst, correction, seq_num, start_time)
Tag(QDatagramSuccess, flow_uuid, seq_num, start_time)

Storage location: message buffers.

Protocol interface:

• EndNodeController creates QDatagram messages for each requested pair.
• NetworkNodeController routes datagrams hop by hop and requests link-level entanglement for the next hop.
• The destination EndNodeController turns a received datagram into QDatagramSuccess, which acknowledges completion back to the source.

Typical query:

querydelete!(messagebuffer(net, node), QDatagram, W, W, node, W, W, W)

Link-Level QTCP Messages

Tag(LinkLevelRequest, flow_uuid, seq_num, remote_node)
Tag(LinkLevelReply, flow_uuid, seq_num, memory_slot)
Tag(LinkLevelReplyAtSource, flow_uuid, seq_num, memory_slot)
Tag(LinkLevelReplyAtHop, flow_uuid, seq_num, memory_slot)

Storage location: message buffers or node-local metadata used by QTCP controllers.

Protocol interface:

• NetworkNodeController produces LinkLevelRequest when a datagram needs entanglement to the next hop.
• LinkController consumes requests and returns LinkLevelReply to the requester and LinkLevelReplyAtHop to the remote hop.
• NetworkNodeController converts replies into forwarded datagrams or source-side bookkeeping through LinkLevelReplyAtSource.
• EndNodeController consumes the source/hop replies when turning a completed datagram into endpoint pair notifications.

Typical queries:

querydelete!(messagebuffer(net, node), LinkLevelRequest, flow_uuid, seq_num, W)
querydelete!(messagebuffer(net, node), LinkLevelReply, flow_uuid, seq_num, W)

MBQC And Purification Interface

These tags are subsystem-specific metadata for graph-state construction and MBQC-based purification.

GraphStateStorage

Tag(GraphStateStorage, uuid, vertex)

Storage location: storage-qubit register slots.

Protocol interface:

• GraphStateConstructor tags each storage qubit with the graph-state uuid and vertex it represents.
• Follow-up graph-state or resource-state protocols can query this tag to find the physical storage slot for a logical graph vertex.

Typical query:

query(reg, GraphStateStorage, graph_uuid, vertex)

PurifierBellMeasurementResults

Tag(PurifierBellMeasurementResults, node, measurements_XX, measurements_ZZ)

Storage location: local register slots and message buffers.

Protocol interface:

• PurifierBellMeasurements produces local bit-packed Bell-measurement results and sends them to the remote chief node.
• MBQCPurificationTracker consumes local and remote results, computes the purification syndrome, and either tags purified pairs or cleans up failed resources.

Typical query:

querydelete!(messagebuffer(net, chief),
    PurifierBellMeasurementResults, remote_chief, W, W)

PurifiedEntanglementCounterpart

Tag(PurifiedEntanglementCounterpart, remote_node, remote_slot)

Storage location: storage-qubit register slots.

Protocol interface:

• MBQCPurificationTracker produces this tag when purification succeeds.
• Custom consumers can query it to find purified Bell pairs without knowing the internal purification workflow.

Typical query:

query(reg, PurifiedEntanglementCounterpart, remote_node, W; assigned=true)

Exact Type Reference

struct EntanglementCounterpart

struct EntanglementHistory

struct EntanglementUpdateX

struct EntanglementUpdateZ

struct EntanglementDelete

struct SwitchRequest

struct Flow

struct QTCPPairBegin

struct QTCPPairEnd

struct QDatagram

struct QDatagramSuccess

struct LinkLevelRequest

struct LinkLevelReply

struct LinkLevelReplyAtSource

struct LinkLevelReplyAtHop

struct PurifierBellMeasurementResults

struct PurifiedEntanglementCounterpart

Where To Go Next

• Read Tagging and Querying for the generic tag and query API.
• Read Metadata and Protocol Composition for the design model behind protocol communication.
• Read Predefined Networking Protocols for the protocol implementations that produce and consume these tags.
